Yaqin MS-110B KT88 vacuum tube Integrated Amplifier
100% Brand New
come with Remote Control and Headphone output
Declaration
All items guaranteed 100% BRAND NEW in the original edition Box.
ONE-YEAR WARRANTY !!!
Parameters:
MMS-110B push-pull amplifier
Circuit features:
● Improved export power boldly use the latest equipment supervisor KT88-98 and the strong push-pull output circuit.
● first level of "SRPP" circuit and the excellent "long tail" type inverter circuit. So that a wider frequency response and better sound quality.
● Audio output transformer uses special silicon steel imported from Japan (0.35mm thick) and oxygen-free high strength enameled wire and special winding process multi-group production (divided into 15 layers), so that the machine wide frequency response, to ensure that the machine is high, , the low-frequency sound good, transparent and powerful.
● The machine adopts the famous factory sound foreign private and non-polarized electrolytic grade fever Philips (MKP) capacitors and manufacturing high-quality gold blocking the main channel with dedicated audio imported from Japan (ALPS) volume motor potentiometer, with quiet background music, noise low, no coloration, and durable.
● high-voltage power supply for the automatic time delay control, can effectively extend the tube life.
● ad hoc super-linear (UL) and three-pole (TR) connection capabilities to meet different user needs.
● function with remote control and headphones.
Specifications:
●Output Power:54W+54W (6ohms)
●Vacuum tube: KT88 x 4 , 12AU7 x 2 , 12AT7 x 2
●Frequency:10Hz-65kHz(-2dB)
●Signal/Noise Ratio:≥85dB (A)
●Input Sensitivity:≤0.3V (1kHz)
●Ohms:4 - 8 ohms
●Degree of Distortion:≤1.9% (1kHz)
●Power Consumption: 300W
●Power supply voltage: 110/220V 60Hz/50Hz
(110V，120V, 127V, 230V, 240V version will
take 3-14 work days to order),
220V version is in stock
●Net Weight: 25.5kg
●Gross Weight: 30kg
●Dimensions: 465 × 396 × 212 (mm)
●Packing size: 610 × 510 × 365 (mm)
