YAQIN MS-2A3 2A3 x4 Vacuum Tube HI-FI INTEGRATED AMPLIFIER New

All items guaranteed 100% BRAND NEW in the original edition Box.

ONE-YEAR WARRANTY !!!


Features of this machine circuit:

1.The front stage is "SRPP" amplifier and long tail inverter circuit.
2.The 2A3C transistor push-pull amplification, low internal resistance, good damping characteristics and choke coil filtering.
3. Special earphone output function, you can directly use earphone to listen to the bladder.
4.With infrared volume and selective conversion remote control function.
5.This machine is made of enthusiast electrolytic and non-polar audio special (MKP) Philips cross-connected capacitors and high-precision metal resistors for audio from famous foreign manufacturers.
6.output transformer alignment using audio-dedicated silicon steel sheet in Japan (Z11 0.35mm thick) and oxygen copper insulated wire and special wound multilayer hierarchical grouping process.
7.The main channel uses a special potentiometer imported from Japan (ALPS) remote control volume, which has the characteristics of quiet music background, low noise, no sound staining and durability.
8.high voltage power supply for the automatic delay control energization, can effectively extend tube life.


SPECIFICATIONS:

Performance Index

Output power: 10W+ 10W(8Q)
Signal to noise ratio: ≥82db (A)
Harmonic distortion: ≤2.5% (1KHz)
Frequency response: 6Hz-70KHz (-2db)
Input sensitivity: ≤0.2V (1KHz)
Tube: 2A3Cx4 12AU7 x212AX7Bx2
Volume: length 590mmx width 470mmx height 380mm
Gross weight: 28kg
Maximum power consumption: ≤150W
